Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
DML-21C-L10 (Serie/s DM)
Swivel castor 50 mm, 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Hub length | 44 mm |
| Height | 72 mm |
| Offset | 30 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 55 mm |
| Load capacity | 60 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
DML-21C-P60 (Serie/s DM)
Swivel castor 50 mm, 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Hub length | 44 mm |
| Height | 72 mm |
| Offset | 30 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6,2 mm |
| Dist. between holes | 38x38-48x48 mm |
| Brake swivel radius | 55 mm |
| Load capacity | 60 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
DSF-31C-L10 (Serie/s DS)
Swivel castor with total brake mounted behind 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 99 mm |
| Offset | 30 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 99 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
DSF-31C-P77 (Serie/s DS)
Swivel castor with total brake mounted behind 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 103 mm |
| Offset | 30 mm |
| Top plate dimensions | 77x66 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/56x46 mm |
| Brake swivel radius | 99 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
DSL-31C-L10 (Serie/s DS)
Swivel castor 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 99 mm |
| Offset | 30 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 68 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
DSL-31C-P77 (Serie/s DS)
Swivel castor 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x25 mm |
| Hub length | 60 mm |
| Height | 103 mm |
| Offset | 30 mm |
| Top plate dimensions | 77x66 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/56x46 mm |
| Brake swivel radius | 68 mm |
| Load capacity | 100 kg |
Wheel
- double wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
EHL
EHR
GMF-21G-P60 (Serie/s GM)
Swivel castor with total brake mounted behind 50 mm - 100 mm, 75 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Hub length | 22 mm |
| Height | 69 mm |
| Offset | 23 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6,5 mm |
| Dist. between holes | 38x38-48x48 mm |
| Brake swivel radius | 75 mm |
| Load capacity | 75 kg |
Wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- plain bearing
- non-oiling
- on request further variants available
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
GMF-31C-L10 (Serie/s GM)
Swivel castor with total brake mounted behind 75 mm - 100 mm, 60 kg - 75 kg
Technical data
| Diameter | 75 mm |
| Tread width | 25 mm |
| Hub length | 28 mm |
| Height | 98 mm |
| Offset | 24 mm |
| Bolt hole diameter | 11 mm |
| Brake swivel radius | 81 mm |
| Load capacity | 60 kg |
Wheel
- TPE tread (Shore A 87)
- polypropylene wheel body
- thread guard
- ball bearing
- non-oiling
- on request further variants available
Areas of application
- bedside cabinets
- brochure display stands
- computer tables
- display stands
- dustbins
- file carts
- garment stands
- greeting card dispensers
- housekeeping carts
- infusion stands
- newspaper dispensers
- sales stands
- small furniture
- sport equipment
