Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
301033 (TANGO)
Fixed castor 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 141 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor (fixed)
- maintenance-free construction
- on request also available with other wheel variants
Areas of application
- Laundry carts
- bedside cabinets
- electronic equipment
- medical & diagnostic equipment
- transport trolleys
301041 (TANGO)
Fixed castor 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 148 mm |
| Top plate dimensions | 77x67 mm |
| Top plate hole diameter | 8 mm |
| Dist. between holes | 61/51x50/42 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor (fixed)
- maintenance-free construction
- on request also available with other wheel variants
Areas of application
- Laundry carts
- bedside cabinets
- electronic equipment
- medical & diagnostic equipment
- transport trolleys
301719 (TANGO)
Swivel castor 75 mm - 125 mm, 70 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 73 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301731 (TANGO)
Swivel castor with total brake mounted behind 75 mm - 125 mm, 70 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 94 mm |
| Load capacity | 70 kg |
Wheel
- elastic rubber tyre (Shore A 60)
- polyamide wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301743 (TANGO)
Swivel castor 75 mm - 125 mm, 90 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Stem size | 10x16 mm |
| Brake swivel radius | 73 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301755 (TANGO)
Swivel castor with total brake mounted behind 75 mm - 125 mm, 90 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Stem size | 10x16 mm |
| Brake swivel radius | 94 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301767 (TANGO)
Swivel castor with directional lock 75 mm - 125 mm, 90 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Stem size | 10x16 mm |
| Brake swivel radius | 94 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301779 (TANGO)
Swivel castor 75 mm - 125 mm, 70 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 117 mm |
| Top plate dimensions | 77x67 mm |
| Top plate hole diameter | 8 mm |
| Dist. between holes | 61/51x50/42 mm |
| Brake swivel radius | 73 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
301791 (TANGO)
Swivel castor with total brake mounted behind 75 mm - 125 mm, 70 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 117 mm |
| Top plate dimensions | 77x67 mm |
| Top plate hole diameter | 8 mm |
| Dist. between holes | 61/51x50/42 mm |
| Brake swivel radius | 94 mm |
| Load capacity | 70 kg |
Wheel
- thermoplastic rubber tyre (Shore A 80)
- polypropylene wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
304395 (TANGO)
Swivel castor with total brake mounted behind 75 mm, 90 kg
Technical data
| Diameter | 75 mm |
| Tread width | 32 mm |
| Height | 110 mm |
| Bolt hole diameter | 10 mm |
| Brake swivel radius | 94 mm |
| Load capacity | 90 kg |
Wheel
- soft polyurethane tyre (Shore A 80)
- polyamide wheel wheel body
- integrated plastic thread guards
- ball bearing
Technical description
- TANGO plastic castor
- sealed precision ball bearings in swivel section
- maintenance-free construction
- Fittings: 10 and 12 mm bolt hole, threaded stem and plate
- on request also available with another wheel variants
Areas of application
- medical equipment
- transport trolleys
- food transport equipment
- laundry carts
- etc.
