Medical Equipment Castors

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from COLSON are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

Swivel castor 75 mm - 50 mm, 50 kg - 40 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 56 mm
Offset 17 mm
Threaded stem size M08x15 mm
Load capacity 40 kg

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture

Swivel castor 75 mm - 125 mm, 50 kg - 80 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 60 mm
Offset 17 mm
Top plate dimensions 38x38 mm
Top plate hole diameter 5 mm
Dist. between holes 25x25 mm
Load capacity 40 kg

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture

Swivel castor 125 mm - 100 mm, 80 kg - 60 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 56 mm
Offset 17 mm
Stem size 11x20 mm
Load capacity 40 kg

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture

Swivel castor with wheel locking brake 75 mm - 50 mm, 50 kg - 40 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 56 mm
Offset 17 mm
Threaded stem size M08x15 mm
Load capacity 40 kg
Weight 90 g

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture

Swivel castor with wheel locking brake 75 mm - 125 mm, 50 kg - 80 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 60 mm
Offset 17 mm
Top plate dimensions 38x38 mm
Top plate hole diameter 5 mm
Dist. between holes 25x25 mm
Load capacity 40 kg
Weight 106 g

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture

Swivel castor with wheel locking brake 125 mm - 100 mm, 80 kg - 60 kg

Technical data

Diameter 50 mm
Thread width 2x11 mm
Height 56 mm
Offset 17 mm
Stem size 11x20 mm
Load capacity 40 kg

Wheel

  • wheel bandage of polyurethane (PU-RAL 7015)
  • soft running surface (for hard floors)

Technical description

  • housing and wheel made of polyamide (PA-RAL 7035)
  • attachments zinc-plated

Areas of application

  • audio furniture
  • bedside cabinets
  • display stands
  • occasional tables
  • serving trolleys
  • small furniture
354a 29G100r ZPF

Fixed castor 100 mm - 125 mm, 100 kg

Technical data

Diameter 100 mm
Thread width 30 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre silver grey RAL7001
  • without thread guard
  • plain bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods

Fixed castor 125 mm - 100 mm, 100 kg

Technical data

Diameter 100 mm
Thread width 30 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre and thread guard silver grey RAL7001
  • precision ball bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods

Fixed castor 125 mm - 100 mm, 100 kg - 80 kg

Technical data

Diameter 100 mm
Thread width 32 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 80 kg
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • sheet steel metal rim zinc passivated
  • metal thread quard
  • flange bearing

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods
357a 29G100r Z522

Swivel castor 100 mm - 125 mm, 100 kg

Technical data

Diameter 100 mm
Thread width 30 mm
Height 132,5 mm
Offset 41,5 mm
Stem size 24x45 M8/19 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre silver grey RAL7001
  • without thread guard
  • plain bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • swivel bearing with double ball race
  • zinc passivated
  • also available with plate PD (77x67 mm) and bolt hole LC (11 mm)

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods
